Double-side High-speed Rotary Label Printing Machine - 轮转商标印刷机系列

MHL-1008S- Double-side High-speed Rotary Label Printing Machine

CHARACTERISTICS ADVANTAGES MAIN TECHNICAL VARIABLES

The rotary machine is one of MINGHUI brand 1-8 color high speed rotary printing machine. can under the high speed of 60m/min printing patterns and double-sided printing function at the same time, such as positive 6 color,/6 against 1/5against 2 /4against 3,and other functions. In our printing machine printed images is accurate and bright clarity, can printing all kinds of fabric tape, such as silk ribbon、satin ribbon, nylon belt, paper ribbon、cotton belt, elastic belt and so on ...

1. The machine use Danfoss (HOLIP) converter performance more stable.
2. Adopt crank connecting rod type is strung together, string together ink institutions make dough evenly.
3. Automatic lubricating device using machine no noise.
4. Independent printing, not affect the normal operation and less wear
5. The polymer plate replace steel metal version, greatly reduce the plate making fee
6. High speed, high efficiency,and printing clearer.
7. Machine design and production technology reasonable, operation is convenient and practical.

Model	MHL-1002S	MHL-1003S	MHL-1004S	MHL-1005S	MHL-10061S	MHL-1008S
Printing Area	MAX 394x95 mm
Printing Speed	Standard 60m/min
Printing Materials	ribbon,silk,nylon bands, cotton bands, paper bands, and elastic bands
Power	220V/1.8KW			220V/2.5KW
Weight	750kg	800kg	850kg	950kg	1050kg	1200kg
Dimensions	1100x850x1400mm	1400x850x1400mm		1930x850x1650mm	2100x850x1750mm
